Prefabricated Vertical Drains

India's Leading PVD Contractor & Ground Improvement Specialists

Ground Improvement Solutions

What is PVD?

Prefabricated Vertical Drains (PVD), also known as wick drains, are one of the most effective and economical ground improvement techniques for accelerating the consolidation of soft, compressible soils.

PVD works by providing a shorter drainage path for pore water to escape from the soil. When combined with surcharge loading, PVD can dramatically reduce the time required for soil consolidation from years to just a few months — enabling faster construction of embankments, highways, ports, airports, and industrial facilities.

Since the development of the synthetic prefabricated vertical drain in the late 1970s, Yadav Constructions has been one of the leading PVD contractors in India. We have installation rigs available for each soil type, varying from very soft soils to very stiff intermediate layers.

3–27m+

Depth Range

50M+

Meters Installed

22+

Years Experience

PVD

Specialists

Process Visualization

Precision PVD Engineering

Advanced ground improvement technology in action — accelerating soil consolidation through precision-engineered PVD installation.

Our Expertise

PVD Expertise & Capabilities

Our heavy installation sets are engineered to penetrate any type of soil where PVD is required, with rigs designed for containerized transport to any project location in India.

🪨

All Soil Types

Our rigs handle very soft soils to very stiff intermediate layers, ensuring PVD installation success regardless of ground conditions.

🇮🇳

Pan-India Deployment

Installation rigs designed for containerized transport — ready to ship to any project location across India within days.

📐

Depths up to 27m+

We have encountered and successfully installed PVD at depths from 3 meters to over 27 meters across varied geological profiles.

⚓

Automatic Anchoring

Advanced automatic anchoring systems keep drains precisely at depth during mandrel retraction for consistent quality.

⚙️

Hydraulic Power

Mandrels driven by excavator hydraulic systems for maximum penetration force even in the most challenging soil conditions.

🚛

Rapid Mobilization

Complete rig setup and mobilization to new sites within 48 hours, minimizing project timeline delays.

Installation Process

5-Stage PVD Process

Our proven installation methodology ensures consistent quality and optimal ground improvement outcomes.

Drain Installation

The prefabricated vertical drains are installed using our wide range of stitchers to enhance anchoring into the subsurface soil layers.

Anchor Attachment

The drain extension located at the base of the mandrel may be attached to an anchor plate or rod for secure, precise placement.

Automatic Anchoring

Automatic anchoring systems are also available, keeping the drain at depth during retraction of the mandrel for consistent installation quality.

Drain Cutting & Reset

After the mandrel has reached the surface, the drain is cut and a new anchor plate is connected to the bottom of the next drain.

Hydraulic Drive System

The mandrel is pushed into and retracted from the ground through a system of cylinders which are propelled by the excavator's hydraulic system.

Our Fleet

Machinery & Equipment

Our comprehensive fleet of PVD installation machinery is maintained to the highest standards, ensuring maximum uptime and consistent installation quality on every project.

Volvo 460/480 Base Machine

03 Nos

Hydraulic Stitcher (Rig) – up to 22m depth

10 Nos

30 KVA Generator

10 Nos

Calyx Rotary Bore Hole Machine

02 Nos

Welding Machines & Tools

Full Set

PVD Leadership

Our PVD Experts

Lakshman Kanara

MD & CEO

"Vast experience across India's infrastructure projects, from civil works to large-scale power plants. Under his leadership, Yadav Constructions has successfully executed complex mandates for both Government and Corporate clients.

Quality Infrastructure

Gopala Krishna

Director – PVD Operations

"With 22+ years of dedicated PVD experience, Gopala Krishna leads our operations with unrivaled soil consolidation expertise, managing massive installations for top-tier clients like Reliance and PSA India.

PVD Client Portfolio
